StructureExpert Weld

StructureExpert Weld is the only stand-alone dedicated imaging tool designed for efficient and accurate weld bead control. Unique inverted optical system, automatic lighting, focus, and calibration eliminate time-consuming manual processes and measurement errors. Now, the weld inspection processes can be improved, thus saving time, money, and resources.

StructureExpert Weld facts:

• Unique inverted optical system
• Dedicated Software
• Efficient process management

StructureExpert Weld-6

Optimal repeatability and easy operation. Dedicated imaging system for weld bead measurement. Consists of compact housing, LED lighting system, Full HD 1080P digital camera with motorized zoom, and dedicated software for measurement and reporting.

• Field of view from ~ 82 to 1.8 mm (~ 3.2” to ~ 0.07”)
• Equivalent to ~ 2.5x - ~ 120x optical magnification

StructureExpert Weld-11

Optimal repeatability and easy operation. Dedicated imaging system for weld bead measurement. Consists of compact housing, LED lighting system, digital camera with motorized zoom and dedicated software for measurement and reporting.

• Field of view from ~ 9.3 to ~ 0.8 mm (~ 0.36” to ~ 0.03”)
• Equivalent to ~ 20x - ~ 240x magnification

Datasheet

For more information please visit the official website of Struers.
